CYLINDER HEAD
90-828631R3 MARCH 1999 Page 4A-7
Camshaft/Oil Pump
TORQUE
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 PIN (Included with Cyl. Block)
2 1 SPRING
3 1 TENSIONER ASSEMBLY
4 1 SCREW (M8 x 20) 220 18.5 25
5 1 SCREW 70 8
6 1 SPACER
7 1 LOAD RING
8 2 WASHER
9 1 GEAR–Drive
10 1 KEY
11 1 BELT
12 1 SCREW (M8 x 40 x 1.25) 28 38
13 1 WASHER
14 1 GEAR–Driven
15 1 OIL SEAL
16 1 DOWEL PIN
17 1 CAMSHAFT
18 1 PIN
19 1 OIL PUMP ASSEMBLY
20 1 O RING
21 1 O RING
22 1 O RING
23 4 SCREW (M6 x 40) 68.0 7.5
