Mercury 40 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
Page 5A-18 90-828631R3 MARCH 1999
5. Install remaining co-pilot components.
54275
54276
a
b
c
d
e
f
g
a-Brake Disc (2)
b-Swivel Head Plate
c-Hex Shoulder Screw (2)
d-Brake Plate
e-Nylon Washer
f-Co-Pilot Lever
g-Lock Nut (Tighten Next Step)

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
