POWER TRIM
Page 5C-10 90-828631R3 MARCH 1999
Tilt Up
Tilt Relief Pressure
250-400 psi (30-60 hp)
500-700 psi (40-60 hp Bigfoot)
540-990 psi (75-125 hp)
Up Pressure
1625 psi (30-60 hp)
2800 psi (75-125 hp)
minimun
Reservoir Oil
Filtered Feed Oil
Oil Under Pressure
Return Oil
Í
Í
Í
Í
Impact Relief Pressure #22
880-1110 psi (30-60 hp)
1220-1420 psi (75-125 hp)
a
b
c
d
w
v
u
t
h
e
f
g
s
r
p
o
g
n
m
k
j
i
l
q
