Mercury 40 Service Manual

THROTTLE/SHIFT LINKAGE
90-828631R3 MARCH 1999 Page 7A-3
Linkage (Non Bigfoot)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 SCREW (M8 x 70) 100 11.3
2 1 SCREW (M6 x 55)
3 1 NUT
4 1 CAP
5 1 RETAINER
6 1 THROTTLE LEVER
7 1 BUSHING
8 1 RETAINER
9 1 SHIFT LEVER
10 1 BRACKET NON HANDLE
11 1 LATCH
12 2 SCREW (M6 x 16) 75 8.5
13 2 SLEEVE
14 1 SHIFT ROD
15
1 THROTTLE CAM
15
1 THROTTLE CAM (40 ITALIAN)
16 1 SPACER
17 1 WASHER
18 1 SCREW (M5 x 16) 75 8.5
19 1 HORIZONTAL SHIFT SHAFT
20 1 RETAINER
21 1 WASHER
22 1 COTTER PIN
23 1 SPRING
24 2 SPRING
25 1 PLATE
26 2 SCREW (M5 x 16)
27 1 SWITCH
28 2 SCREW (M3 x 20) HANDLE MODELS
29 1 PLATE–Switch
