Section 5 - Maintenance
90-866938081 MAY 2009 Page 109
13. Using a 6M Allen wrench, tighten the filter assembly screw to specification.
a - Assembly screw
b - Fluid filter assembly
Description Nm lb‑in. lb‑ft
Filter assembly screw 7 62 –
IMPORTANT: Use new sealing washers to avoid leaks.
14. On models with a drop box, install the drain cap. Tighten the drain cap to
specification.
a - Drop box
b - Drain cap
Description Nm lb‑in. lb‑ft
Drop box drain cap 50 – 37
