Meva MevaLite - Page 42

ML-42
MevaLite
Wall Braces
Information for the push-pull
prop R brace type including load
capacity and adjustment range is
shown in Table42.1.
Table 42.1
1
Primary value listed is based on application as brace installed at 60° to horizontal and accounts for MevaLite
panel connection with multi-function profile transverse working load limit of 1576 lb. Value in [brackets] is safe
working load of brace alone.
2
Tension value in (parentheses) is MevaLite multi function profile pullout working load limit.
Push-pull prop R
Description Adjustment range Compression Tension
Safe working load
1,2
(lb)
Length Safe working load
1
(lb)
R 160 4'-6" to 6'-6" 6'-6" 1819 [5620] 1819 (3682) [5620]
R 250 6'-3" to 10'-5" 6'-3" 1819 [5845] 1819 (3682) [5845]
7'-1" 1819 [5845]
8'-9" 1819 [5620]
10'-5" 1819 [3372]
R 460 11'-2" to 17'-0" 11'-2" 1819 [5620] 1819 (3682) [5620]
12'-4" 1819 [5620]
14'-1" 1819 [4721]
14'-8" 1819 [4047]
15'-10" 1819 [3372]
17'-0" 1819 [2698]
R 630 16'-9" to 24'-11" 16'-9" 1819 [6519] 1819 (3682) [7419]
18'-4" 1819 [5395]
19'-6" 1819 [4721]
20'-8" 1819 [4047]
21'-8" 1819 [3597]
23'-3" 1819 [2923]
24'-11" 1819 [2473]
Wall formwork
Technical Instruction Manual / June 2022
