Meva MevaLite - Page 43

MevaLite
ML-43
Wall Braces
Information for the SRL and RSK
brace types including load capacity
and adjustment range is shown in
Tables43.1 and 43.2.
Table 43.1
1
Primary value listed is based on application as brace installed at 60° to horizontal and accounts for MevaLite
panel connection with multi-function profile transverse working load limit of 1576 lb. Value in [brackets] is safe
working load of brace alone.
2
Tension value in (parentheses) is MevaLite multi function profile pullout working load limit.
Brace SRL
Description Adjustment range Compression Tension
Safe working load
1,2
(lb)
Length Safe working load
1
(lb)
SRL 120 3'-0" to 4'-11" 3'-0" 1819 [6744] 1819 (3682) [6744]
4'-11" 1819 [6744]
SRL 170 3'-11" to 7'-3" 3'-11" 1819 [6744] 1819 (3682) [6744]
5'-11" 1819 [6744]
7'-3" 1819 [4496]
Table 43.2
Brace RSK
Description Adjustment range Compression Tension
Safe working load
1,2
(lb)
Length Safe working load
1
(lb)
RSK 1 3'-0" to 4'-11" 3'-0" 1819 [8992] 1819 (3682) [8992]
4'-11" 1819 [8992]
RSK 4 8'-6" to 13'-1" 8'-6" 1819 [8543] 1819 (3682) [8992]
9'-5" 1819 [7194]
10'-10" 1819 [5171]
11'-3" 1819 [4721]
13'-1" 1819 [2698]
1
Primary value listed is based on application as brace installed at 60° to horizontal and accounts for Imperial
panel connection with multi-function profile transverse working load limit of 1576 lb. Value in [brackets] is safe
working load of brace alone.
2
Tension value in (parentheses) is Imperial multi function profile pullout working load limit.
Wall formwork
Technical Instruction Manual / June 2022
