Control CS 310 / Rev.I 1.55 – 25
AUTOMATIC STANDBY
P
>1 sec.
ADJUSTMENT STANDBY
+
-> Position DOOR OPEN
ADJUSTMENT MAIN UP
Save door position:
P
Keep pressed and
+
> 1 sec.
-
-> Position DOOR CLOSED
ADJUSTMENT MAIN DOWN
Save door position:
P
Keep pressed and
-
> 1 sec.
P
>1 sec.
INPUT
+
and
-
> 2 sec.
INPUT DEUTSCH
Scroll up through menu:
+
> 2 sec.
Scroll down through menu:
-
> 2 sec.
Select value:
P
>1 sec.
Increase value:
+
Decrease value:
-
Save value:
P
Return to INPUT:
+
and
-
> 1 sec.
FINE-UP 0
P
>1 sec.
FINE-DOWN 0 INC.P.OP A INC.P.CL A OPEN TIME OFF START WARN. OFF FOREWARNING OFF AUT.CLOSE MOD1 FAST CL. OFF RELAY 1 MOD6 RELAY 2 MOD7 RELAY 3 MOD1 RELAY 4 MOD14 TL REST MOD1 SKS A DW TEST MOD2 DW-POINT 20 SKS FKT. MOD1 SKS REV MOD1 REVERSPOINT. OFF 50 LIGHT BARR. 1 A LB FUNC 1 MOD1 LB FUNC 2 MOD1 PEP POINT A IMPULS MOD1 INPUT 1 MOD1 INPUT 2 A SKS3 MOD1 SKS4 MOD1 RUNNINGTIME A AROUNDTIME 300 LIMIT SW. A SELF LOCK MOD1 POWER 10 RESET MSBUS OFF RESTART OFF FACTORY SET. 99 RESET OFF PIN NO.2 1111 SERVICE OFF INVERTER MOD1 EXPERT MENU OFF
DIAGNOSIS
Scroll up through menu:
+
> 2 sec.
Scroll down through menu:
-
> 2 sec.
Return to AUTOMATIC:
P
Only queries are possible.
ES UP ON ES DOWN ON OPEN BUTTON OFF CLOSE BUTTON OFF INPUT 1 OFF INPUT 2
/ SKS OPEN 2 / SAFE. 2 – / ON / OFF
SKS ON SKS 3
/ SAFE. 3 – / ON
SKS 4
/ SAFE. 4 – / ON
IMPULS OFF SWITCH CLOCK OFF LIGHT BARR. ON LIGHT BARR2 ON SAFETY CIRC. ON STOP ON ROT FIELD Right CYCLE 000000 SERVICE OFF AWG 0000 C.OPENED 0000 C.STOP 0000 C.O.BTN 0000 Error Memory Error …
