MFZ Ovitor Control CS 310 User Manual

34 – Control CS 310 / Rev.I 1.55
Overview of functions
10.3 10.3 Explanation of the relay modes:Explanation of the relay modes:
A. Trafclightfunctions
MOD Description CLOSED end position OPEN end position Forewarning Door run
MOD1 Redtrafclightinside1 ON / OFF
1
OFF
2
Flashing Lit up
MOD2 Redtrafclightinside2 ON / OFF
1
OFF
2
Flashing Flashing
MOD3 Redtrafclightinside3 ON / OFF
1
OFF
2
Lit up Lit up
MOD18 Redtrafclightinside4 OFF OFF Flashing OFF
MOD23 Greentrafclightinside OFF ON
2
OFF OFF
MOD44 Redtrafclight
inside + outside
OFF OFF OFF Flashing
3
MOD60 Redtrafclight
outside1
ON / OFF
1
OFF
2
Flashing Lit up
MOD61 Redtrafclight
outside2
ON / OFF
1
OFF
2
Flashing Flashing
MOD62 Greentrafclight OFF ON
2
OFF OFF
1
Dependent on parameter T-LI. REST
2
Iftwo-waytrafccontrolisactivated:dependentoninsideoroutsideOPENcommand
3
from intermediate position DOWN to limit position DOWN, also after stop command
B. Position messages
MOD Description Remarks
MOD6 OPEN end position The relay closes the contact when the door is at the OPEN end position.
MOD7 CLOSED end position The relay closes the contact when the door is at the CLOSED end position.
MOD8 Not OPEN end position The relay closes the contact when the door is not at the OPEN end position.
MOD9 Not CLOSED end position The relay closes the contact when the door is not at the CLOSED end position.
MOD10 Intermediate OPEN position (Part OPEN) The relay closes the contact when the door is at the intermediate OPEN position (part OPEN).
MOD11 Intermediate CLOSE position (Part
CLOSED)
The relay closes the contact when the door is at the intermediate CLOSE position
(Part CLOSED).
MOD12 Intermediate CLOSE position to CLOSED
end position
The relay closes the contact when the door is in the area between the CLOSED end position and
the intermediate CLOSE position (Part CLOSED).
MOD19 Intermediate OPEN position to OPEN end
position
The relay closes the contact when the door is in the area between the OPEN end position and
the intermediate OPEN position (Part OPEN).
