26 – Control CS 310 / Rev.I 1.55
Display Description
AUTOMATIC
TEACH IN RUN
Automatic teach-in of the running time
AUTOMATIC
OPEN
The door is in the opening phase.
AUTOMATIC
CLOSE
The door is in the closing phase.
AUTOMATIC
STANDBY
The door is at an intermediate position.
AUTOMATIC O
STANDBY
The door is at the OPEN end position.
AUTOMATIC o
STANDBY
The door is at the part OPEN position (“INC.P.OP” or “Intermediate OPEN position” parameter).
AUTOMATIC U
STANDBY
The door is at the CLOSED end position.
AUTOMATIC u
STANDBY
The door is at the part CLOSED position (“INC.P.CL.” or “Intermediate CLOSED position” parameter).
AUTOMATIC r
STANDBY
The door is in the reversing switch-off position.
AUTOMATIC
PERMANENT INPUT
When the power is switched off, an active signal (NO) is detected at the UP, DOWN, pulse or programmable
input 1 (with use of I/O BUS modules, also inputs 11-14 or 15-18).
This constitutes an invalid state under any circumstances. This state is probably caused by a faulty component
which needs to be replaced.
Exception: An exception to this is if the signal comes from the pluggable timer or the programmed input 1
whenthisissettoatimerfunction(MOD4)orrealarmfunction(MOD5-9,13).
AUTOMATIC
CRASH-SENSOR
The crash sensor for the door/gate system has been activated (connection to X4/9-10, programmable input 1
MOD 18). Possibly a vehicle (such as a forklift truck) has driven into the closed door.
SERVICE
STANDBY
The pre-selected service interval has been reached.
If the “PRESS/REL“ parameter is set to MOD2, 3, 4, 5 or MOD6 in the input menu, the display changes from AUTOMATIC to MANUAL.
Display Description
MANUAL
MAIN UP
The door is in the opening phase.
MANUAL
MAIN DOWN
The door is in the closing phase.
MANUAL
STANDBY
The door is at an intermediate position.
10. Overview of functions
10.1 10.1 Automatic operating modeAutomatic operating mode
