MFZ Ovitor Control CS 310 User Manual

40 – Control CS 310 / Rev.I 1.55
MOD Description Remarks
MOD31 OPEN button outside When the button is pressed, the door opens as far as the OPEN end position.
Thetrafclightoutsidechangestogreen.
MOD32 CLOSE button When the button is pressed, the door closes as far as the CLOSED end position.
Only active with operational closing edge safety device and operational photocell 1. No function in
deadman mode.
B. Input 2 functions
MOD Description Remarks
OFF not active
MOD2 Wicketdoorswitch(8.2kΩ) Generally active
Stops the system when actuated.
MOD3 Closing edge safety device OPEN
(8.2kΩ)
Closing edge safety device active in the OPEN direction
Door stops and reverses to the CLOSED end position when the closing edge safety device is
triggered.
MOD4 Closing edge safety device OPEN
(8.2kΩ)
Closing edge safety device active in the OPEN direction
Door stops and moves in the CLOSE direction for 2 seconds (short reverse) when the closing edge
safety device is triggered.
MOD5 Battery operation (MDFU special
solution) n.o.
Active if power supplied by battery.
Relay switching MOD32 / MOD33.
MOD6 Radar motion detector
(height detection) NO
The function is coupled to Input 1 (MOD12 – laser scanner).
The preceding laser scanner detects the height of the vehicle.
The installed radar motion detector generates an OPEN command when actuated.
– A tall vehicle (lorry) will be detected by the laser scanner.
The laser scanner switches Input 1 (MOD12) to ON.
The radar motion detector evaluates the vehicle and triggers the door movement.
The door is moved to the OPEN end position.
– A lower vehicle (car) is recognised by the laser scanner.
The laser scanner switches Input 1 (MOD12) to OFF.
The radar motion detector evaluates the vehicle and triggers the door movement.
The door is moved to the intermediate OPEN position (Part OPEN).
All other OPEN commands (via X3, X7, X9, X13) always move the door to the OPEN end position.
The Input 1 function (MOD12) then has no effect.
MOD7 Light curtain 2 (PNP) with testing Acts in same way as light curtain 1 (SKS MOD 4 – 6)
– Light curtain active in the CLOSE direction.
– Stop and reverse when the light curtain is triggered.
The type of reversing (reverse / short reversal) is also adopted.
Overview of functions
