Control CS 310 / Rev.I 1.55 – 39
MOD Description Remarks
MOD9 Fire alarm (BMA) switch 2
(emergency opening) NC
Controlfunctionifrealarmsystemisactive.
Closed: Normal operation
Open: Emergency opening of door
BUTTON: No function
LIGHT BARR / SKS: No function
STOP: Emergency closing interrupted as long as this is activated.
 Noautomaticclosingafterdeactivationofrealarmsignal.
MOD10 Ventilation button NO Partial opening of the door. When an additional button at Input 1 is pressed, the intermediate CLOSE
position (Part CLOSED) is approached from either direction, irrespective of the current door position.
MOD11 “Automatic closing” button 1. Operation: No automatic closing; the open time continues.
2. Operation: Automatic closing of the door is active again,
if the open time is > 0.
3. Operation: No automatic closing; the open time continues.
…
MOD12 Laser scanner (height detection) Only in conjunction with Input 2 (MOD 6).
➔ See explanation regarding Input 2.
MOD13 Fire alarm (BMA) switch 3
(partial opening) NC
Controlfunctionifrealarmsystemisactive.
Closed: Normal operation
Open: Partial opening of the door. The intermediate OPEN position (PART OPEN) is approached
from either direction, irrespective of the current door position.
BUTTON: No function
 LIGHTBARR/SKS: Doorstopsandbrieyreverses(onlyinCLOSINGdirection),and
closes again after 5 seconds
STOP: Emergency closing interrupted as long as this is activated.
MOD14 Wicket door lock Monitoringlimitswitchforthepneumaticlocksystemforwicketdoors.Thelimitswitchmustconrm
correct locking within 10 seconds of an OPEN command being given, otherwise the door remains
stationary and an error message is given.
This function affects relay mode 36.
MOD15 Photocell 2 NC If a second photocell is installed in the drive-through area of the door, this system can be program-
med via the LB FUNC 2 parameter in INPUT mode.
Only photocells with a potential-free NC contact may be connected.
MOD16 Forewarning switch Closed: Start-up warning and forewarning are inactive
(even if both times are > 0).
Open: Start-up warning and forewarning are active (only when both times are > 0).
➔ “10.2Inputoperatingmode“onpage27
MOD17 Impulse button outside Pressing the button moves or stops the door.
– The function and direction of the movement depend on the IMPULS parameter setting in the
Input menu.
➔ “10.2Inputoperatingmode“onpage27
– Iftwo-waytrafccontrolisactivated,thisimpulsecommandistreatedasasignalfromoutside.
MOD18 Crash sensor (NC) Querying a crash sensor as a NC contact. If the crash sensor has been activated before, door
operation is only possible again
– if the STOP button has been pressed for longer than 5 seconds or
– the supply voltage has been turned off and then on again.
MOD19 Switch block operation commands
NC
Closed: No restrictions.
Open: It is no longer possible to use the (+) and (-) buttons on the LCD monitor and the
motherboard to issue operation commands in AUTOMATIC mode.
MOD30 OPEN button inside When the button is pressed, the door opens as far as the OPEN end position.
Thetrafclightinsidechangestogreen.
