Control CS 310 / Rev.I 1.55 – 41
10.5 Diagnosis / error memory operating mode
Display Meaning Status
UPPER SWITCH OPEN end position OFF: End position reached
ON: End position not reached
LOWER SWITCH CLOSED end position OFF: End position reached
ON: End position not reached
OPEN BUTTON Command button / OPEN input ON: Button activated / input is active
OFF: Button not activated / input not active
CLOSE BUTTON Command button / CLOSE input ON: Button activated / input is active
OFF: Button not activated / input not active
INPUT 1 Programmable INPUT 1 (X4 / 9 + 10) ON: Input 1 active
OFF: Input 1 not active
INPUT 2
SKS OPEN 2 /
SAFE. 2
(optionally)
Programmable INPUT 2
(X4 / 11 + 12)
Input dependent on MOD selected at
the programmable input.
INPUT 2 with MOD 5-7
SKS OPEN 2 with MOD 3-4
SAFE. 2 with MOD 2
ON: Input 2 active
OFF: Input 2 not active
—: Not activated
SKS Closing edge safety device 1
(PSswitch,8.2kΩoroptosensor)
or light curtain 1
(PNP or optosensor)
(X4 / 5-8) CLOSING direction
ON: System closed
OFF: System interrupted (fault)
SKS 3 /
SAFE. 3
(optionally)
Closing edge safety device 3
(8.2kΩoroptosensor)
Radio transmission system channel 1
OPEN or CLOSE direction
Display dependent on MOD selected at
parameter SKS 3.
SKS 3 with MOD 2-3
SAFE. 3 with MOD 4
ON: System closed
OFF: System interrupted (fault)
—: Not activated
SKS 4 /
SAFE. 4
(optionally)
Closing edge safety device 4
(8.2kΩoroptosensor)
Radio transmission system channel 2
OPEN or CLOSE direction
Display dependent on MOD selected at
parameter SKS 4.
SKS 4 with MOD 2-3
SAFE. 4 with MOD 4
ON: System closed
OFF: System interrupted (fault)
—: Not activated
IMPULS Command button / IMPULSE input
(X3 / 7+8)
ON: Button activated / input is active
OFF: Button not activated / input not active
