MFZ Ovitor Control CS 310 User Manual

38 – Control CS 310 / Rev.I 1.55
10.4 10.4 Key to inputs:Key to inputs:
A. Input 1 functions
MOD Description Remarks
MOD1 PART OPEN button When the button is pressed (Input 1), the door opens as far as the intermediate OPEN position (PART
OPEN).
MOD2 PART OPEN switch Closed: All OPEN commands lead to the intermediate OPEN position (PART OPEN).
Open: All OPEN commands lead to the OPEN end position.
MOD3 AUTO CLOSE switch Closed: No automatic closing
(open time continues, if open time > 0)
Open: Automatic closing run is activated (if open time > 0)
MOD4 External CLOCK (Continuous OPEN) The door opens once the contact closes and remains in the OPEN position (open time continues)
until the contact opens. The door then closes automatically (only if open time > 0) This function can
be aborted by pressing the CLOSE button. The gate CLOSES.
MOD5 Fire alarm (BMA) switch 3 (partial
opening) NO
Controlfunctionifrealarmsystemisactive.
Open: Normal operation
Closed: Partial opening of the door. The intermediate OPEN position (Part OPEN) is approached
from either direction, irrespective of the current door position.
BUTTON: No function
 LIGHTBARR/SKS: Doorstopsandbrieyreverses(onlyinCLOSINGdirection),and
closes again after 5 seconds
STOP: Emergency closing interrupted as long as this is activated
MOD6 Fire alarm (BMA) switch 1
(emergency closing) NO
Controlfunctionifrealarmsystemisactive.
Open: Normal operation
Closed: Emergency closing of door
BUTTON: No function
 LIGHTBARR/SKS: Doorstopsandbrieyreverses;emergencyclosingagainafter5
seconds
STOP: Emergency closing interrupted as long as this is activated
MOD7 Fire alarm (BMA) switch 1
(emergency closing) NC
Controlfunctionifrealarmsystemisactive.
Closed: Normal operation
Open: Emergency closing of door
BUTTON: No function
 LIGHTBARR/SKS: Doorstopsandbrieyreverses;emergencyclosingagainafter
5seconds
STOP: Emergency closing interrupted as long as this is activated
MOD8 Fire alarm (BMA) switch 2
(emergency opening) NO
Controlfunctionifrealarmsystemisactive.
Open: Normal operation
Closed: Emergency opening of door
BUTTON: No function
LIGHT BARR / SKS: No function
STOP: Emergency closing interrupted as long as this is activated.
 Noautomaticclosingafterdeactivationofrealarmsignal.
