MFZ Ovitor Control CS 310 - Explanation of Relay Modes (Continued); Input-Dependent and System Message Relay Modes

EN
Control CS 310 / Rev.I 1.55 – 37
H. Input-dependent messages
MOD Description Remarks
MOD32 Battery mode Active during battery operation. Input 2 bridged (setting MOD5)
MOD33 Not in battery mode Active during mains operation. Input 2 open (setting MOD5)
When programmed with MOD32/33, the relays work as delayed change-over contacts and follow
the signal at Input 2 if set to MOD5.
In this case, input 2 is supplied with a control signal from the uninterruptible power supply (UPS)
system which is responsible for switching between mains power and the UPS power supply.
MOD34 BMA signal Triggeredifrealarmsystem(BMA)active.
Follows the signal at Input 1 if set to MOD5-9 / 13.
Inthiscase,Input1issuppliedwithacontrolsignalfromtherealarmsystem,anddependingon
the setting, opens or closes the door to an end position or an intermediate position.
I. System messages
MOD Description Remarks
MOD31 Service The relay is active after reaching the programmed service interval. Only after the service interval is reset or
redeneddoestherelaydropoutagain.
➔ “10.2Inputoperatingmode“onpage27 /Parameter SERVICE
MOD46 ADJUSTMENT operating mode The relay is active if the control is in the ADJUSTMENT operating mode.
