MFZ Ovitor Control CS 310 User Manual

36 – Control CS 310 / Rev.I 1.55
F. Movement signal
MOD Description Remarks
MOD29 Door OPENS. Active during OPENING movements.
MOD30 Door CLOSES. Active during CLOSING movements.
MOD43 Door opens or closes. Active during every movement.
G. Functions for external accessories
MOD Description Remarks
MOD13 Magnetic lock function The relay closes before each door movement. The relay is normally open.
A delay of 0.5 seconds is programmed to elapse before each door movement takes
place.
MOD21 Test of draw-in protection The relay generates a test signal when the CLOSED end position is reached and
expects, as a reaction to the test signal, that the stop circuit is actuated.
MOD22 Activation of radio transmission systems 1 and 4,
testing of light curtain 1
The relay generates a test signal when the OPEN end position is reached and
expects, as a reaction to the test signal, that the closing edge safety device input is
actuated.
MOD24 Capacitor Whenever a door movement command is given, the relay closes for approximately
1second.Withtheaidofthisrelay,anadditionalstartingcapacitorthatisrequired
for AC applications is switched on, to ensure safe starting of the motor.
For operators of the STAW range with increased duty cycle.
MOD25 Yard light function At every OPEN command, the relay is closed for 2 minutes and can therefore be used
to control a light.
MOD26 Activation of radio transmission systems 2 and 4 Before every CLOSE command, the radio transmission system is activated by an
impulse. The duration of the activation must be set on the transmission system.
This activation results in a 0.5 second delay in starting.
MOD28 Relay OFF The relay is generally switched off; the contact is always open.
MOD36 Pneumatic cylinder for locking the wicket door
(threshold-less door system).
Every time an OPEN command is given, the relay is activated and controls a
pneumatic cylinder which mechanically locks the wicket door that is incorporated in
the door. The locking position of the cylinder is queried through a limit switch. The
door starts moving only after this limit switch has been released. The relay remains
activated until the lower end position has been reached again.
MOD37 Testing of the stop signal via
radio transmission systems 1 and 3
The relay generates a test signal when the OPEN end position is reached and
expects, as a reaction to the test signal, that the stop circuit is interrupted.
MOD38 Testinglightcurtain2(8.2kΩ)
Connection to input 2 (X4 / 11+12)
The relay generates a test signal when the OPEN end position is reached and
expects, as a reaction to the test signal, that there is an interruption to Input 2.
MOD 41 Activation of radio transmission system 4 in the
OPEN direction
The relay generates a test signal when the CLOSED end position is reached and
expects, as a reaction to the test signal, that there is an interruption to Input 2.
MOD49 Testing presence and movement sensors (NC) The relay generates a test signal each time before closing travel and awaits an
interruption of the closing edge input as a response to the test signal.
Overview of functions
