3. General safety instructions
Failure to comply with the documentation could
result in life-threatening danger!
Be sure to follow all the safety instructions in this docu-
Be sure to follow all the safety instructions in this docu-
ment.
Warranty
The function and safety of the equipment is only guaranteed
if the warning and safety instructions included in these
operating instructions are adhered to.
MFZ Antriebe GmbH + Co. KG is not liable for personal
injury or damage to property if these occur as a result of the
warnings and safety advice being disregarded.
MFZ does not accept any liability or warranty for damage due
to the use of non-approved spare parts and accessories.
Use for the intended purpose
The CS 310 control is intended exclusively for the purpose
of controlling door systems operated using mechanical limit
switches (MEC) or an electronic end position system (AWG
absolute value encoder).
Target group
Onlyqualiedandtrainedelectriciansmayconnect,
programme and test the control.
Qualiedandtrainedelectriciansmustmeetthefollowing
requirements:
− knowledgeofthegeneralandspecicsafetyandaccident
prevention regulations.
− knowledge of the relevant electrical regulations,
− training in the use and care of appropriate safety
equipment.
− capable of recognising the dangers associated with
electricity.
Instructions regarding installation and connection
− The control is designed with X type terminals.
− The system must be disconnected from the electricity supply
before carrying out any electrical work. It must be ensured
that the electricity supply remains disconnected for the
duration of the work.
− Local protective regulations must be complied with.
− Consultthemanufacturerbeforecarryingoutmodications
or replacing the mains connection cable.
Original operating instructions
− Copyright.
− No part of these instructions may be reproduced without
our prior approval.
− Subject to alterations in the interest of technical progress.
− All dimensions given in mm.
− The diagrams in this manual are not to scale.
Key to symbols
WARNING!
Indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
CAUTION!
Indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
Indicates an imminent danger of damage or destruction.
CHECK
Indicates a check to be performed.
REFERENCE
Reference to separate documents which must be complied
with.
Action requestAction request
− List, itemisation
➔ Reference to other sections of this document
