MFZ Ovitor Control CS 310 - Input Operating Mode Functions; Position Adjustment Functions; Automatic Closing and Warning Functions

EN
Control CS 310 / Rev.I 1.55 – 27
10.2 10.2 Input operating modeInput operating mode
Function Description Setting options Factory settings
DEUTSCH Select the menu language.
Only possible using the LCD monitor:
Alternatively, the menu language can also be selected during the initialisation phase
(during initial operation or after a reset). The menu language pre-set in the factory
(DEUTSCH)appearshereforapproximately60secondsasashingtextinthedisplay.
At this point, the menu language can still be changed during the initialisation
procedure.
Pressing buttons [+] or [–] will allow you to scroll through and select a language.
Save the language you have selected by pressing button [P].
After this, all texts or messages displayed are shown in the language that you have
selected.
DEUTSCH
ENGLISH
FRANCAIS
NEDERLANDS
DANSK
ESPANOL
POLSKI
CESKY
ITALIANO
SUOMI
SVENSKA
TÜRKÇE
NORSK
MAGYARUL
DEUTSCH
FINE-UP Fine adjustment of the OPEN end position in relation to the saved OPEN end position
(UPPER SWITCH).
Only visible if an electronic end position system is used.
-250 – 250 0
FINE-
DOWN
Fine adjustment of the CLOSED end position in relation to the saved CLOSED end
position (LOWER SWITCH).
Only visible if an electronic end position system is used.
-250 – 250 0
INC.P.OP Setting the switching point for the intermediate OPEN position (Part OPEN) in relation
to the saved OPEN end position. Displayed as a negative value.
Only visible if an electronic end position system is used.
Automatic teach-in of position:
➔ “7.5 Setting the intermediate positions of the electronic end position system using
the LCD monitor“
A (teach-in)
-1 – LOWER SWITCH
A
INC.P.CL Setting the switching point for the intermediate CLOSE position (Part CLOSED) in
relation to the saved CLOSED end position. Displayed as a positive value.
Only visible if an electronic end position system is used.
Automatic teach-in of position:
➔ “7.5 Setting the intermediate positions of the electronic end position system using
the LCD monitor“
A (teach-in)
1 – UPPER SWITCH
A
OPEN TIME After the door/gate has opened, it runs back automatically in the CLOSE direction
after the set time has elapsed.
Please note:
If you press the CLOSE BUTTON during the open time, the closing run starts immedi-
ately.
If you press the OPEN or STOP button during the open time, the time starts counting
from the beginning again.
If an automatic closing operation is interrupted by the closing edge protective device,
the open time is added to every new attempt. After 3 attempts, the
automatic closing process will be aborted automatically.
OFF,
1 – 3600 seconds
OFF
START WARN. The start warning is carried out before each run. OFF,
1 – 10 seconds
OFF
