Workstation 5 Field Service Guide xi
Preface
How This Manual is Organized
How This Manual is Organized
Welcome to the 1st Edition of the Workstation 5 Field Service Guide.
Chapter 1 lists the Workstation Field Replacement Units (FRUs). This includes
casework, LCD and Touchscreen components, the Workstation 5 system board
and components. Images of each FRU are included to avoid confusion.
Chapter 2 provides technical descriptions of the Workstation 5 System Board with
emphasis on the POS Interfaces including IDN, Customer Display, Mag Stripe
Reader and Cash Drawer interfaces. Other topics include a description of the USB
Interfaces and the System Board Power Distribution.
Chapter 3 covers WS5 troubleshooting. The Chapter starts off with a detailed start
up description of the supported operating systems and provides voltage test points
for the internal power supply and system board voltage regulators.
Chapter 4 includes the FRU remove/replace procedures.
Appendix A includes pin-out diagrams for all WS5 IO Port connectors and related
hook-up cables.
