Workstation 5 Field Service Guide 1-9
Introduction to the WS5 FRUs
Cables
Cables
This section contains all Workstation 5 internal and external cables.
LCD Data Cable - P/N 300331-305
This cable connects between the System Board J8 and the LCD panel data
connector.
Figure 1-5: Workstation 5 LCD Data Cable
Cable, Inverter Board - P/N 300331-210
This cable connects between the System Board J3 and J1 on the Backlight
Inverter Board.
Figure 1-6: Workstation 5 Backlight Inverter Board Cable
