4-22 Workstation 5 Field Service Guide
Remove and Replace the Workstation 5 FRUs
The System Board
Approved DIMMs for the Workstation 5 System Board
Figure 4-24 lists the DDR DIMMs currently approved for use on the
Workstation 5 System Board.
.
Figure 4-24: Workstation 5 System Board Approved DIMMs
Figure 4-25 displays current DDR 333 DIMM configurations for the Windows
CE and WEPOS operating systems using MICROS approved devices.
Figure 4-25: DIMM Configuration Table
Size MICROS P/N Description
256MB 700502-175 Wintec WD1UN256X808-333B-PH
WD1UN256X808-333B-PJ-M01
Unigen UG732D6688KV-DHFMSS
512MB 700502-173 Wintec WD1UN512X808-333B-QC
WD1UN512X816-333B-PJ-M01
1GB 700502-174 Wintec WD1UN01GX816-333C-QC
CN12 CN13 Total Operating System
256MB -- 256MB Windows Embedded
CE 6.0
a
a. MICROS recemmneds that you do not install more than 512MB in
a WS5 running Windows Embedded CE 6.0.
512MB -- 512MB WEPOS
1GB -- 1GB WEPOS
