Workstation 5 Field Service Guide 1-13
Introduction to the WS5 FRUs
Workstation 5 Adjustable Stand Accessories
Workstation 5 Adjustable Stand Accessories
USB Extension Cable and Bracket - P/N 400431-305
Optional USB Extension Cable connects between the Workstation 5 IO panel
and the base of the adjustable stand. Cable appearance may vary.
Figure 1-11: Adjustable Stand USB Extension Cable
Third Party Mounting Adapter for Workstation 5 Stand - P/N 600526-050
The mounting adapter installs in place of the WS5 Adjustable Stand Logo
Badge as shown in the Figure below. It can be used to mount a variety
customer facing devices.
Figure 1-12: Adjustable Stand Third Party Mounting Adapter
