Micros Systems Workstation 5 - Remove and Replace the Workstation 5 FRUs

Workstation 5 Field Service Guide 4-1
Chapter 4
Remove and Replace the
Workstation 5 FRUs
This Chapter describes how to remove and replace Workstation 5 Field
Replaceable Units.
In this chapter
Disassembling the Workstation 5....................................................... 4-2
Magnetic Card Reader .......................................................................4-5
The Power Supply..............................................................................4-7
LCD/Touchscreen Procedures ...........................................................4-8
The System Board............................................................................4-17
The Integrated LCD Customer Display...........................................4-26
Reassembling the Workstation 5......................................................4-27
