Technical Information
22
CVA610 Coffee System
The actuating magnet (Figure 4-8, item 1) for the Waste Unit
Present Switch is located at the bottom edge of the Waste Unit.
Figure 4-8: Waste Unit. (1) Magnet for Waste Unit
Present Switch.
Note
On newer manufactured Waste Units, an additional magnet is
present to keep the waste unit attached to the metal frame inside
the appliance. The magnet for the Waste Unit Present Switch
remains in the same location.
