Miele CVA610 - Bean Container Guide - Removal

Technical Information
76
CVA610 Coffee System
5.38 Bean Container Guide - Removal
1. Open the door.
2. Perform the Beans Container. (5.37)
3. Remove the Waste Container, Brew Unit and Water Tank.
4. Remove the Top Lid (5.1).
5. Remove the screws (Figure 5-40 - Item 2).
6. Remove the guide and carrier, (Figure 5-40 – Item 1).
Note
When refitting, first fit the carrier (Figure 5-40 – Item 1), in position
and then fit the guide on the carrier.
Figure 5-40: Removing the Beans Container guide
