Miele CVA610 - Rear Door Panel - Removal

Technical Information
50
CVA610 Coffee System
5.12 Rear Door Panel - Removal
Refer to figure 5-12.
1. Open the door.
2. Remove the upper rear panel fixing screws (Item 1).
3. Remove the lower rear panel fixing screws (Item 2).
Figure 5-12: Rear Door Panel – Removal.
