Miele CVA610 - Brew Unit Present Switch - removal; Dispensing Solenoid - Removal; Dispenser Switch - Removal

Technical Information
83
C
VA
6
1
0
C
offee
Sy
stem
5.42 Brew Unit Present Switch - removal
1. Remove the Top Lid.
2. Remove the Rear Panel.
3. Disconnect the switch (Figure 5-46, Item 2).
4. Press the retainers outward to remove the switch.
Figure 5-46: Brew unit present switch location and removal.
5.43 Dispensing Solenoid - Removal
1. Remove the Top Lid (5.1).
2. Remove the Rear Panel (5.3).
3. Remove the Beans Container (5.37).
4. Remove the Beans Container Guide (5.38).
5. Press the coil retainers outwards. Slide the coil upwards out of
the guide.
6. Disconnect the coil connections.
5.44 Dispenser Switch - Removal
7. Remove the Top Lid (5.1).
8. Remove the Rear Panel (5.3).
9. Remove the Beans Container (5.37).
1. Remove the Beans Container Guide (5.38).
2. Remove the Dispensing Solenoid (5.34)
3. Press the switch retainers outwards. Remove the switch.
4. Disconnect the connections.
