Miele CVA610 - Brew Unit - Installation; Brew Unit - Cleaning Procedure

Technical Information
61
C
VA
6
1
0
C
offee
Sy
stem
5.24 Brew Unit - Installation
Slide the brew unit into position in the appliance until the locking
mechanism engages with the drive mounting plate.
Note
Do not press the part marked PRESS during the installation of the
brew unit.
5.25 Brew Unit – Cleaning Procedure
Note
- Clean the brew unit by hand only. The moving parts and the
rubber gaskets SHOULD NOT be cleaned in a dishwasher.
- Lubricate the brew unit with silicon every 500 cups (see
"Lubricating the brew unit").
1. Remove the waste unit. The brew unit can only be removed
after the waste unit has been taken out.
2. Grasp the brew unit by the handle and press with the thumb on
"PRESS". (Figure 21 – Item 1).
Figure 5-21: Brew Unit – Removal for Cleaning
