Miele CVA610 - Overflow Switch Actuator Float - Removal

Technical Information
47
C
VA
6
1
0
C
offee
Sy
stem
5.8 Overflow Switch Actuator Float - Removal
1. Remove the Lid, Mains and Rear Panel (5.1 to 5.3)
2. Remove the Base Plate (5.6)
Note
The orientation of the float before removal – ensure it is re-installed
in the same direction.
3. Remove the Float.
Figure 5-8: Overflow Switch Float
