Technical Information
87
VA
1
offee
stem
5.49 Water Connections - Fitting
1. Check the Sealing Rings for damage - replace as necessary.
2. Fit the Sealing Rings on the hose.
3. Insert the Hose into the Connector.
4. Fit the Retaining Spring behind the Pressed-On Ring.
5. Ensure the Hose cannot be pulled from its Connector.
Note
The Pressed-On Rings cannot be replaced as a separate
component. Should replacement be necessary the hose (as an
assembly) must be replaced.
