Technical Information
78
CVA610 Coffee System
10. Turn the adjustment ring (Figure 5-42, Item 1),
counterclockwise until the blue marking aligns with the blue
marking on the carrier (Figure 5-42, Item 2).
Figure 5-42: Upper Section of Grinder (1) Adjustment Ring, (2) Carrier & (3)
Bracket.
11. Remove the bracket (Figure 5-42, Item 3)
12. Remove coffee residues, e.g. with a vacuum cleaner.
Note
The grinding cone fixing screw has a left-hand thread.
13. Remove the grinding cone fixing screw (Figure 5-43, Item 1) by
turning it clockwise.
14. Remove the intake worm gear (Figure 5-43, Item 2).
15. Remove the washer (Figure 5-43, Item 3).
