Technical Information
20
S 500 & S 600 Canister Vacuums
5. Remove the seal (Figure 010-4, Item 2) and sealing ring (Figure 010-4,
Item 1).
Figure 010-4: Seal and Sealing Ring Removal
Note:
When re-installing, ensure that the seal and sealing ring are seated
correctly.
4.4 Caster Removal
1. Lever out the support roller with a screwdriver. See Figure 010-5.
Figure 010-5: Levering Out the Support Roller
2. Remove the 2 shaft screws.
