Technical Information
53
S
500 & S 600 Canister Vacuums
Figure 030-13: Levering Out the Foot Switch
Note:
Do not lever with the screwdriver in the middle as the retainer can then break.
4.7 Plug Housing Removal
1. Remove the casing top; see Section 020-4.2.
2. Remove the cap; see Section 030-4.1.
3. Remove the on/off switch from its holder.
4. Remove the plug housing screws; see Figure 030-14, Item 1. Remove the
plug housing.
Figure 030-14: Plug Housing Removal
