Technical Information
57
S
500 & S 600 Canister Vacuums
Figure 030-20: Gear Rack Removal (S 52x, S 62x)
5. When re-installing, push the slide to the maximum setting and hold it there.
6. Turn the cog wheel to its end stop. See Figure 030-19. Hold it in position
and install the bracket.
4.11 Park System Switch Removal
1. Remove the plug housing. See Section 030-4.7.
2. Disconnect the switch plug connections.
3. Use a screwdriver to release the switch locking tabs. See Figure 030-21, Item 2.
Figure 030-21: Park System Switch Removal
4.12 Cap Electronic Replacement
1. Remove the plug housing. See Section 030-4.7.
2. Disconnect the on/off switch plug connections from the old electronic.
3. Connect the on/off switch plug connections to the new electronic.
