Miele S 528 - Bag Holder Removal; Figure 010-6: Bag Holder Removal; Figure 010-7: Spring Position

Technical Information
21
S
500 & S 600 Canister Vacuums
4.5 Bag Holder Removal
1. Open the casing top.
2. Remove the bag.
3. Press the 2 tabs out of the way and remove the bag holder. See Figure
010-6, Item 1.
Figure 010-6: Bag Holder Removal
Note:
When installing, the spring must rest on the outer retainers. See Figure 010-7.
Figure 010-7: Spring Position
