Milestone Srl MA213-003 – DMA-80 EVO – User Manual
14
Pull back the horizontal pneumatic actuator in
order to free the catalyst flange.
Loosen the red screw on the spectrophotometer
plate and move far the spectrophotometer arm.
Loosen the two red screws on the slide rails.
It is not necessary to remove completely the
screws
