Milestone Srl MA213-003 – DMA-80 EVO – User Manual
81
5.13 Measure page
After the login, the software skips directly into the page Measure/Sample. The last measuring file of the
current user is opened, if available.
Here it is possible to run unknown samples, insert the points for the calibration curve, run reference
samples and a lot of other actions.
5.13.1 Measurement- Parameters
Different sub-sections with different options and functions are available in Measure page:
Sample/Links/Signal and Result.
Some filed are not available in some sub-sections, therefore if you want to get them be sure that you are
in the right page.
In order to set up a sample, the user can pass through these sections from left to right and new samples
can be added at any time, also during ongoing measurements.
- The section Sample allows to enter comments on samples and to create multiple measurements.
- The section link allows to select the suitable working method and calibration which are introduced in the
quick selection. If only a calibration or method is used, please remove all the others from the quick
selection, in order to avoid confusion or any mistake. In this case it’s no longer necessary to enter this
page.
- The section Signal allows to view all parameters of the signals.
- The section Results, shows all results, including the possibility of a statistic analysis, calibration factor
and methods with volume indication of dilution factor.
Pos “1” (available in all sub-sections): It is the position of the autosampler plate
where the sample is loaded. The number of position can be changed by the user
(1): it is the sequential number of the measurements which continuously
increases by 1 for each record. It can not be changed.
