Milestone Srl MA213-003 – DMA-80 EVO – User Manual
30
Note: the connections are different if you use air or O2. The outlet connection must be suitable
to connect 6x4 Rilsan tube.
2.4.1 Oxygen tank
Connect the DMA-80 EVO unit to the O2 source
thanks to 6x4 Rilsan blue tube you can find in the
accessories box.
To avoid damages to the pressure regulator
diaphragm, open the tank valve and adjust the
pressure on the oxygen tank/air source from 0 to
4 bar.
Once the unti is switched ON the DMA-80 EVO
internal pressure is set to 3,1 bar.
2.4.2 Milestone Air compressor
Please refers to Milestone Air compressor User Manual
Take the air compressor from its box and place
it on the floor
