Milestone Srl MA213-003 – DMA-80 EVO – User Manual
49
5.10.2.1 USB storage on terminal 660
There are several USB ports available on terminal 660 (or 1660). The UBS key can be connected to all
USB ports available on the terminal, but always only one at a time.
In case you want to change the USB key, then, first of all you have to remove the one currently connected
and then, introduce the new one.
The other outputs are used to connect printer, mouse, keypad and barcode reader.
Mobile storage area: The USB memory is used to save methods, sample tables and measurement data.
It is also used as signature to work in accordance with CFR Part 11.
The directory for the USB key in the terminal is A:\ (USB-Stick).
Storage: The terminal is supplied with a USB key. All memory sizes can be used. If the files are very
small, few MB as memory is enough.
5.10.2.2 Storage on the LAN connection
In terminal 660 (or 1660) it’s also possible to save files on a shared directory of NFS- or CIFS- server.
The procedure is described in the chapters 5.15.1.3
5.10.3 Main page DMA-80 EVO Software
After the login, the software operations pages will appear. There are different windows, all on the same
level. More details about the single pages are described in the next chapters.
You can move through the windows and select the different icons by touching the touch-screen or by the
mouse click.
Popup menu described in chapter 5.10.1
Here you can manage your methods. It’s possible to create, edit, save and delete
methods. In each method you can set the heating, amalgamator, flushing and
recording time of the measurement programs. Appropriate basic methods are
automatically uploaded upon delivery.
Here you can manage the calibration files. From a calibration file, you can
choose the measurement points for the calibration and the type of regression
curve for each cuvette. You can find also a control chart of the reference sample.
This window and its subpages represent the main user interface. Here you can
set the sample weighing as well as recording and evaluation of the signals and
also the output of the results.
Here the status of the system is monitored (position of pneumatic cylinders and
autosampler, temperatures of heating elements and detector voltages).
