Legend:
n. Pneumatic section
o. Autosampler plate
p. Drying/decomposition furnace
q. Catalyst furnace
r. Amalgamator furnace
s. Power supply 24V
t. Hg power supply
u. Hg lamp
v. Cuvette
w. Dual beam option (optional)
x. Cooling fans.
y. Autosampler led
x
t
u
s
v
w
o
r
p
q
n
x
x
y
