3-2. Miscellaneous Symbols And Definitions
Amperes
Output
Gas Tungsten Arc
Welding (GTAW)
Volts
Voltage Input
Three Phase Static
Frequency Convert-
er-Transformer-
Rectifier
Voltage Output
Remote
Seconds
On
Off
Positive
Negative
Alternating Current
(AC)
Water (Coolant)
Input
Water (Coolant)
Output
Cooling
Gas Input
Gas Output
Rated Welding
Current
Duty Cycle
Direct Current
Line Connection
Conventional Load
Voltage
Primary Voltage
Degree of
Protection
Rated Maximum
Supply Current
Maximum Effective
Supply Current
Rated No Load
Voltage (OCV)
Initial Amperage
Rated Cooling
Power (Coolers)
Rated Maximum
Pressure (Coolers)
Increase/Decrease
Of Quantity
Percent
Hertz
Pulser
Pulse Frequency
Process
Suitable for Welding
in an Environment
with Increased Risk
of Electric Shock
Shielded Metal Arc
Welding (SMAW)
Protective Earth
(Ground)

A complete Parts List is available at www.MillerWelds.com
OM-270536 Page 4
1-2. Miscellaneous Symbols And Definitions
Pulse Background
Amperage
Normal Trigger
Operation
(GTAW)
Two-Step Trigger
Operation
(GTAW)
Four-Step Trigger
Operation
(GTAW)
Contactor Control
(Stick)
Pulser On-Off
Pulse Background
Amperage
