MIMAKI UJV-160 User Manual

3-15
3
Useful Function
Setting the UV LED level
Set when you do not want to light the UV LED.
1
When <LOCAL> is displayed, press the
key.
2
Press the key.
3
Select the type 1 to 4 with the
key, and press the key.
4
Select the [UV LEVEL] with the
key, and press the key.
5
Select the level with the key,
and press the key.
• As for the options, see the table below.
6
Press the key to finish.
Item Outline
HIGH The UV LED lights at 100% illuminance.
STANDARD The UV LED lights at 75% illuminance.
LOW The UV LED lights at 50% illuminance.
NONE The UV LED does not light during drawing.
NO PRINT
Only the UV LED lights without drawing. Use when curing ink after drawing in
case that the UV LED did not light during drawing.
<LOCAL . 1>
FUNCTION
FUNCT I ON
SET UP <ENT>
ENTER
SET UP
SELECT : TYPE1
ENTER
[1]
UV LEVEL < e n t >
ENTER
[1]UV LEVEL
SETUP : H I GH
ENTER
END
