System Calibration
Cal
ibration
4 - 72
046-001141-00
A5/A3™ Service Manual
F
o
r O2 and AIR, set th
e output pressure using the ta
ble below
. F
or
N2O
, set the output pressure to 58
psi.
1.
T
urn off the power suppl
y and all gas supplies
. Open the ser
vice door
.
FIGURE 4-91
2.
Remove the sheet metal
at the rear of the equipment.
cylinder pressure (psi)
regulator press
ure (psi)
1000
52.2
1250
50.6
1500
49
1750
47.4
2000
47.1
2250
46.8
257
259
