Mindray Accutorr 7 Service Manual

6-4
2. Remove the recorder or recorder cover, and pull the rear housing out as indicated
below to separate the front and rear housing.
3. Stand the monitor and separate the front housing assembly and rear housing assembly
with caution. Disconnect the cable between the main board and power management board
and then take off the front panel.
NOTE
 When reassembling the equipment, be sure to check if the front housing
waterproof strip is correctly placed.
Cable
