Mindray BC-2800 - Chapter 3 Disassembling the Analyzer

Disassembling the Analyzer
Chapter3 Disassembling the Analyzer
3.1 Main Unit Structure
3.1.1 Main user interfaces
2
1
6
5
4
3
Figure 3-1 Front view
Front view:
1 ---- LCD
2 ---- Keypad
3 ---- Recorder
4 ---- Power Indicator
5 ---- [START] key
6 ---- Sample Probe
3
4
5
6
1
2
Figure3-2 Rear view
Rear view:
1 --- Power switch
2 --- Equipotentiality
3 --- Waste Outlet (Red)
4 --- Lyse Inlet (Orange)
5 --- Rinse Inlet (Blue)
6 --- Diluent Inlet
(Green)
BC-2800 Auto Hematology Analyzer (V1.0) 3- 1
