Mindray BC-2800 - Left View

Disassembling the Analyzer
Left view:
1 --- RS232 Port1
(for the scanner)
2 --- Parallel Port
3 --- RS232 Port 2
(for the computer)
4 --- Power Interface of Floppy
Disk Drive
5 --- Keyboard Interface
Figure3-3 Left view
3-2 BC-2800 Auto Hematology Analyzer (V1.0)
