Mindray BC-2800 Service Manual

Chapter 6 Maintenance
desired screen from there.
6.2.1 Diluent Prime
Biohazard
Wear standard laboratory attire (including rubber gloves) and
follow safe laboratory procedures when handling any material in
the laboratory.
You should perform the Diluent prime procedure to prime the diluent tubing
with diluent when
 there are bubbles in the tubing; or
 the diluent in the tubing is contaminated; or
 the old diluent ran out and a new container of diluent is installed.
Follow the steps given below to do so
 At the Maintenance screen, press the appropriate arrow keys ([↑][↓][←][→])
to move the cursor to Diluent Prime.
 Press [ENTER] to prime the tubing with diluent and the priming progress will be
displayed at the bottom of the screen, as Figure 6-3 shows.
 When the priming is done, the screen will return to the initial state.
Figure 6-3 Diluent priming screen
BC-2800 Auto Hematology Analyzer (V1.0) 6-5

Mindray BC-2800 Specifications

General

Reagents	Diluent, Lyse, Cleaner
Power Supply	AC 100-240 V, 50/60 Hz
Power Consumption	≤150 VA
Printer	Built-in thermal printer
Type	Hematology Analyzer
Parameters	WBC, RBC, HGB, HCT, PLT
Sample Volume	20 μL
Display	Large LCD display
Data Storage	10, 000 sample results
Interface	RS232, USB
Operating Environment	Temperature: 15-30°C, Humidity: 30-85%
Storage Environment	Temperature: -10-55°C, Humidity: ≤93%
