Disassembling the Analyzer
Figure3-11
3.2.9 Removing the transformer
As the figure below shows, remove the retaining screws (totally 2) with a socket
wrench.
Figure3-12
3.2.10 Removing valves
As the figure below shows, remove the retaining screws (two for each valve) to
remove the valves.
BC-2800 Auto Hematology Analyzer (V1.0) 3- 7
