Disassembling the Analyzer
Figure3-16
3.2.14 Removing the pump assembly
As the figure below shows, remove the retaining screws (totally 7) to remove the
assembly.
Figure3-17
3-10 BC-2800 Auto Hematology Analyzer (V1.0)
