Mindray Eagus TEX21 - Page 289

B Wireless Charging
Operator’s Manual B - 7
4. Install the transmitting module onto the wall mounting bracket, as shown in the following
figure.
5. Connect the power cord to the external power supply and use a Velcro to organize the power
cord.
If wall mounting installation is selected and the pad does not need to be installed, the operation
steps are as follows:
1. Mark a straight line at the wall 15 cm above the ground with a marking pen.
